Model | Single/ Double | Frequency | Power | Voltage | Current | Max airflow | Rated Vacuum | Rated compress | Noises | Weight | |
Hz | kW | V | A | m3/h | mbar | mbar | dB(A) | Kg | |||
3HB350-1H16 | Single | 50 | 2.2 | 200-260A | 350-450Y | 8.1 A/4.6Y | 315 | -190 | 170 | 64 | 45 |
60 | 2.55 | 230-290A | 400-500Y | 8.0A/4.6Y | 370 | -150 | 130 | 68 | |||
3HB 350-1H26 | Single | 50 | 3.0 | 200-260A | 350-450Y | 11.4A/6.5Y | 315 | -290 | 270 | 65 | 50 |
60 | 3.45 | 230-290A | 400-500Y | 10.8A/6.2Y | 370 | -250 | 220 | 69 | |||
3HB 350-1H37 | Single | 50 | 4.0 | 350-450A | 610-725Y | 8.4A/4.8Y | 315 | -350 | 390 | 65 | 62 |
60 | 4.6 | 400-500A | 690-725Y | 8.2A/4.7Y | 370 | -370 | 340 | 69 | |||
3HB 350-1H47 | Single | 50 | 5.5 | 350-450A | 610-725Y | 11.1 A/6.4Y | 315 | -350 | 500 | 65 | 74 |
60 | 6.3 | 400-500A | 690-725Y | 11.0A/6.4Y | 370 | -390 | 510 | 69 | |||
3HB 350-2H26 | Double | 50 | 3.0 | 200-260A | 350-450Y | 11.4A/6.5Y | 320 | -230 | 190 | 68 | 68 |
60 | 3.45 | 230-290A | 400-500Y | 10.8A/6.2Y | 380 | -150 | 120 | 71 | |||
3HB 350-2H37 | Double | 50 | 4.0 | 350-450A | 610-725Y | 8.4A/4.8Y | 320 | -350 | 310 | 69 | 79 |
60 | 4.6 | 400-500A | 690-725Y | 8.2A/4.7Y | 380 | -280 | 230 | 72 | |||
3HB 350-2H47 | Double | 50 | 5.5 | 350-450A | 610-725Y | 11.1 A/6.4Y | 320 | -530 | 480 | 71 | 90 |
60 | 6.3 | 400-500A | 690-725Y | 11.0A/6.4Y | 380 | -480 | 390 | 74 | |||
3HB 350-2H57 | Double | 50 | 7.5 | 350-450 A | 610-725Y | 15.0A/8.7Y | 320 | -530 | 700 | 71 | 97 |
60 | 8.6 | 400-500A | 690-725Y | 15.1 A/8.8Y | 380 | -580 | 610 | 74 | |||
3HB 350-2H67 | Double | 50 | 11 | 350-450A | 610-725Y | 22.0A/12.7Y | 320 | -530 | 870 | 72 | 120 |
60 | 12.6 | 400-500A | 690-725Y | 22.0A/12.9Y | 380 | -580 | 930 | 76 | |||
3HB 350-3H37 | Triple | 50 | 4.0 | 350-450A | 345-415Y | 8.4A/4.8Y | 320 | -300 | 250 | 69 | 82 |
60 | 4.6 | 400-500A | 690-725Y | 8.2A/4.7Y | 380 | -200 | 150 | 72 | |||
3HB 350-3H47 | Triple | 50 | 5.5 | 350-450 A | 610-725Y | 11.1 A/6.4Y | 320 | -490 | 410 | 71 | 93 |
60 | 6.3 | 400-500A | 690-725Y | 11.0A/6.4Y | 380 | -410 | 300 | 74 | |||
3HB 350-3H57 | Triple | 50 | 7.5 | 350-450A | 610-725Y | 15.0A/8.7Y | 320 | -680 | 620 | 71 | 100 |
60 | 8.6 | 400-500A | 690-725Y | 15.1 A/8.8Y | 380 | -650 | 510 | 74 | |||
3HB 350-3H67 | Triple | 50 | 11.0 | 350-450A | 610-725Y | 22.0A/12.7Y | 320 | -680 | 1020 | 72 | 120 |
60 | 12.6 | 400-500A | 690-725Y | 22.0A/12.9Y | 380 | -650 | 880 | 76 | |||
3HB 350-3H77 | Triple | 50 | 15.0 | 350-450 A | 610-725Y | 30.5A/17.3Y | 320 | -680 | 1020 | 72 | 136 |
60 | 17.3 | 400-500A | 690-725Y | 29.5A/17.0Y | 380 | -650 | 1050 | 76 | |||
3HB 550-1H26 | Single | 50 | 3.0 | 200-260A | 350-450Y | 11.4A/6.5Y | 480 | -130 | 120 | 69 | 66 |
60 | 3.45 | 230-290A | 400-500Y | 10.8A/6.2Y | 565 | -70 | 60 | 74 | |||
3HB 550-1H37 | Single | 50 | 4.0 | 350-450A | 610-725Y | 8.4A/4.8Y | 480 | -230 | 200 | 69 | 78 |
60 | 4.6 | 400-500A | 690-725Y | 8.2A/4.7Y | 565 | -170 | 140 | 74 | |||
3HB 550-1H47 | Single | 50 | 5.5 | 350-450 A | 610-725Y | 11.1 A/6.4Y | 480 | -380 | 330 | 69 | 88 |
60 | 6.3 | 400-500A | 690-725Y | 11.0A/6.4Y | 565 | -310 | 260 | 85 | |||
3HB 550-1H57 | Single | 50 | 7.5 | 350-450A | 610-725Y | 15.0A/8.7Y | 480 | -380 | 500 | 69 | 96 |
60 | 8.6 | 400-500A | 690-725Y | 15.1 A/8.8Y | 565 | -410 | 440 | 85 | |||
3HB 550-2H47 | Double | 50 | 5.5 | 350-450A | 610-725Y | 11.1 A/6.4Y | 480 | -270 | 220 | 70 | 118 |
60 | 6.3 | 400-500A | 690-725Y | 11.0A/6.4Y | 580 | -180 | 130 | 74 | |||
3HB 550-2H57 | Double | 50 | 7.5 | 350-450 A | 610-725Y | 15.0A/8.7Y | 480 | -450 | 370 | 70 | 126 |
60 | 8.6 | 400-500A | 690-725Y | 15.1 A/8.8Y | 580 | -370 | 280 | 74 | |||
3HB 550-2H67 | Double | 50 | 11.0 | 350-450A | 610-725Y | 22.0A/12.7Y | 480 | -530 | 630 | 70 | 145 |
60 | 12.6 | 400-500A | 690-725Y | 22.0A/12.9Y | 580 | -540 | 530 | 74 | |||
3HB 550-2H77 | Double | 50 | 15.0 | 350-450A | 610-725Y | 30.5A/17.3Y | 480 | -530 | 890 | 70 | 156 |
60 | 17.3 | 400-500A | 690-725Y | 29.5A/17.0Y | 580 | -540 | 870 | 74 | |||
3HB 550-3H57 | Triple | 50 | 7.5 | 350-450 A | 610-725Y | 15.0A/8.7Y | 480 | -380 | 280 | 71 | 142 |
60 | 8.6 | 400-500A | 690-725Y | 15.1 A/8.8Y | 580 | -240 | 140 | 77 | |||
3HB 550-3H67 | Triple | 50 | 11.0 | 350-450A | 610-725Y | 22.0A/12.7Y | 480 | -610 | 540 | 71 | 167 |
60 | 12.6 | 400-500A | 690-725Y | 22.0A/12.9Y | 580 | -590 | 390 | 77 | |||
3HB 550-3H77 | Triple | 50 | 15.0 | 350-450A | 610-725Y | 30.5A/17.3Y | 480 | -610 | 830 | 71 | 180 |
60 | 17.3 | 400-500A | 690-725Y | 29.5A/17.0Y | 580 | -590 | 680 | 77 | |||
3HB 550-3H87 | Triple | 50 | 18.5 | 350-450 A | 610-725Y | 37.0A/21.0Y | 480 | -610 | 1020 | 71 | 195 |
60 | 21.3 | 400-500A | 690-725Y | 36.5A/21.0Y | 580 | -590 | 870 | 77 |
